Emergency Stop Accessories for Electrostatic Spraying Equipment with Fast Response Time
Equipment Description:
Principle of electrostatic spraying process: Use electrostatic powder spraying equipment (electrostatic spraying machine) to spray powder coating onto the surface of the workpiece. Under the action of static electricity, the powder will be evenly adsorbed on the surface of the workpiece to form a powder coating; the powder coating is leveled and solidified after high-temperature baking to become a final coating with different effects (different types of powder coating effects); the spraying effect is better than the painting process in terms of mechanical strength, adhesion, corrosion resistance, and aging resistance, and the cost is also lower than the painting with the same effect.
1. Core advantages of equipment Efficient spraying : The maximum processing capacity of a single machine is 300㎡/h (the workpiece spacing is ≥0.5m) Precise adsorption : Intelligent adjustment of electrostatic field strength, complex surface coverage rate reaches 98% Zero pollution emission : 100% solid powder utilization, no VOC generation
2. Safety protection design Triple interlocking protection: Overvoltage/overcurrent/excessive powder concentration automatically cuts off the power supply Emergency stop response time <0.2 seconds Comply with GB 5226.1-2025 "Mechanical and Electrical Safety" standard
Main structures and components:
1. Main structure composition
1. Electrostatic generation system
High frequency high voltage generator: Output 0-100kV adjustable DC voltage, current ≤50μA (safety anti-electric shock design).
Electrostatic spray gun: Rotary cup electrode, adjustable rotation speed 2000-30000rpm
Atomization particle size 15-40μm, powder charging efficiency ≥95%
Grounding device: Workpiece grounding resistance ≤4Ω, to ensure the uniformity of electrostatic adsorption.
2. Powder supply system
Fluidized bed powder supply barrel: Compressed air fluidized powder (pressure 0.05-0.15MPa), powder suspension density deviation ≤±3%.
Venturi powder pump: gas-solid mixing ratio 1:2, conveying distance ≤8m (no sedimentation blockage).
Fast color change module: color change time ≤10 minutes (with modular powder supply pipe + color powder recovery bin).
3. Recycling and purification system
Secondary cyclone recovery: primary recovery rate ≥ 85%, powder particle size > 10μm.
Filter element precision recovery: secondary recovery rate ≥ 95% (PTFE coated filter element, precision 0.3μm).
Safety and explosion-proof design: powder concentration monitoring (automatic shutdown at 20% lower explosion limit).
2. Auxiliary function module
| Components |
Technical parameters |
Functional description |
| Thermostatic control system |
20-25℃±1℃ PID temperature control |
Prevent powder from agglomerating and stabilize fluidization |
| Automatic cleaning device |
Pulse backwash frequency 0.5-5Hz adjustable |
Real-time cleaning of residual powder in the spray gun |
| Workpiece identification sensor |
Laser distance measurement + photoelectric switch, positioning accuracy ±1mm |
Trigger the start and stop of the spray gun to reduce waste of empty spraying |
3. Key Components Technical Specifications
1. Electrostatic Spray Gun
Material: Carbon Fiber Reinforced Composite Material (High Pressure and Wear Resistance)
Applicable Powder: Epoxy/Polyester/Acrylic, Particle Size Range 10-120μm
Spraying Efficiency: 120-200g/min (Adjusted according to the complexity of the workpiece)
2. Powder Recovery System
Comprehensive Utilization Rate ≥ 96% (Including Screening and Reuse of Recycled Powder)
Emission Index: Particles < 5mg/m³ (GB 16297-2025)
3. Intelligent Control Unit
PLC+HMI Human-Machine Interface, 20 Sets of Preset Spraying Parameters
Real-time Monitoring: Voltage/Current/Powder Flow/Workpiece Speed (Data Storage ≥ 3 Years)
Features:
1.High cost performance: Based on the customer's product positioning and development strategy, and with economic affordability as the foundation, we achieve the best cost performance.
2.The advanced and meticulous design concept of the equipment, along with the highly automated industrial equipment, showcases the image of a modern and advanced enterprise.
3. It has high adaptability, meeting the current production requirements and reserving room for development, taking into account the needs of increased production and improved quality in the future.
4.Quality compliance strictly adheres to the ISO900 quality management system, with every minute detail of the entire equipment installation being strictly controlled.
